The liquid crystal display device has a thin edge, but as a special large screen display equipment, its installation and debugging is very complicated and important link, in order to realize the system function in everyday applications, often also need to be equipped with other devices, such as matrix, distributor, cable etc.. At present, many manufacturers are trying to make the installation structure becomes simple. To this end, the modular structure design of the advanced LCD splicing screen with a built-in high performance processing module and other unique technology, such as the built-in digital matrix, the display installation and management system is very convenient. Modular design makes the system installed without complicated wiring, only need access to power lines and network lines to achieve the operation of the equipment. And management is also very convenient, only through powerful professional splicing control software for LCD splicing system management and control. This design greatly reduces the installation and management costs of the splicing screen. Therefore, modularization is the development trend of splicing unit in the future. The modular structure of splicing unit will make installation and debugging more and more simple.

Characteristic description

The whole hardware structure of the system:

LCD as basic display unit;

High display resolution, delicate screen, rich in content;

Area, small size, light weight;

Longer display life;

No radiation, low power consumption, high display efficiency;

Integrated RGB/VGA, composite video, DVI signal input;

Support multi-channel RGB/VGA/DVI signal real-time display;

Any user control picture in picture mode;

Images can be superimposed in real time, cross screen roaming;

All signal parallel real-time processing;

Start time less than 10 seconds;

High stability, boot immediately work, arbitrary power off;

Can be 24 hours of continuous work;

Easy to operate, no need to install complex software.
